Renkforce RF500 Maker Construction Kit - B) Wiring of the Electrical Components

71
b)WiringoftheElectricalComponents
IfyouconnectacabletothemainPCB,rstcheckthecorrectconnectioninthefollowingwiringdiagram.
ConnectionplanofthemainPCB
Line Length Connection
Main PCB
Pin number of plugs
(allpinsonblackplugs;colour
based on pin1)
Component Pin number of plugs
(allpinsonwhiteplugs;colour
based on pin1)
01 990 mm
D9 2pin brown/white, open Extruder fan 2pin brown/white
END STOPS 2pin yellow/green LimitswitchXdirection 2pin yellow/green
02 220 mm END STOPS 2pin white/brown Limit switch Z-direction 2pin white/brown
03 920 mm D10 2pin red, open ends Heating cartridge extruder 0 2pinred,xed
04 980 mm T0 2pin white Temperature sensor extruder 0 2pinwhite,xed
05 890 mm
X 4pin yellow/brown/green/white MotorX-direction 6pin white/brown/green/yellow
END STOPS 2pin pink/grey LimitswitchY-direction 2pin pink/grey
06 450 mm Y 4pin yellow/white/green/brown MotorY-direction 6pin brown/white/green/yellow
07 500 mm Z 4pin yellow/white/green/brown Motor Z-direction 6pin yellow/green/white/brown
08 280 mm E0 4pin yellow/white/green/brown Motorextruder0(lamentinfeed) 6pin brown/white/green/yellow
09 85 mm Green plug 2pin red/black, open Jumper connection plug mains unit 2pin red/black, open
Endschalter Z (02)
Endschalter X (01)
Endschalter Y (05)
Extruder Temp. (04)
LCD EXP1
Motor Ext. 0 (08)
(oberer Pin = braun)
Trimmer Motorstrom Ext.
Trimmer Motorstrom X
Trimmer Motorstrom Y
Trimmer Motorstrom Z
Motor X (05)
oberer Pin = weiß)
Motor Z (07) (oberer Pin = braun)
Motor Y (06) (oberer Pin = braun)
Reset
LCD EXP2
Extruder Heizung (03)
+
Lüfter (01)
+
Spanungsversorgung
12 V/DC, 5 A (09)
C1
220 µF, 35 V
