d)ManualOperationviatheSoftware
Click the tab "Manual Control"(1)onthemainscreenofthesoftware.
Beforetryingoutmanualprintercontrol,thesettingsforthelimitswitchesfortheZandYaxesmusthavebeenperformed.
Inthepreassembleddevice,thebasicsettingshavealreadybeenperformedatproductionbutshouldbeinspectedagain
for reasons of safety.
 Ifthisisnotobserved,theremaybedamagetothe3Dprinter(lossofwarranty/guarantee).
(2) Allaxesmoveintothehomeposition
(3) X-axismovesintothehomeposition
(4) Y-axismovesintothehomeposition
(5) Z-axismovesintothehomeposition
(6) Thearrowiconscanbeusedtooperatethecorrespondingaxesmanually.Dependingonwherethearrowisclicked,differentlylongroutes
are run. The route length is displayed when the mouse pointer is moved across the corresponding button of the arrow.
(7) Selectingtheextruder(optional)
(8) Filamentfeedforthechosenextruder(extrudermustbeheatedup!)
(9) Settingoftheprintingspeed
(10)Switchingthefanon/off;Totherightofthis,thespeedcanbeset
(11)Switchingtheheatingbed(inthepreassembleddeviceorwhenusingtheoptionallyavailableheatingplatekit)on/off;thetemperaturecan
be set on the right
(12)Switchingtheextruderheaterforthe1stextruder(inthermwareextruder0)on/off;Totherightofthis,thetemperaturecanbeset
1
2
3
5
9
8
7
4
10
6
6
12
11
