14.OperationatthePrinter
a) Display and Operating Buttons
(1) Temperatureextruder(target)
The target temperature it not displayed here yet, since the ex-
truder is not heated yet.
(2) Temperatureextruder(actual)
(3) Printingspeed
(4) Statusinformation
(5) Statusoftheheatingbed(optional)
(6) Statusoftheextruderfan;whenitruns,thecurrent
speed in % is displayed below.
(7) Statusandpositionofthe3axesX,YandZ;indicationinmm
(8) StatusoftheSDcard
(9) Settingcontrollerforthedisplaycontrast
  (adjustablewithanarrowat-headscrewdriver)
(10)Operatingknobwithbutton
Turn to the left/right: Direction navigation in the menu structure;
Setting the temperature, positions
  Button:Toconrmaselectioninthemenu
(11)Resetbutton:Restartstheprinter
