5.2.3 Film infeed
The staged plan for the Film infeed operational mode is described in Table 6.
Table 6 Start film indeed
No.
Action
Remark
1.
Check that no-one else is working on or
with the machine.
Go on to the next stage only when
the machine is free.
2.
Go through the steps indicated in Table 4
(see paragraph 5.2.1.)
-
3.
Turn the main switch on, position, “1”.
See Figure 5.2,
4.
Using the operator menu, turn the heating
elements on and allow the machine 15
minutes to come up to temperature.
Use the button on the control
panel:
5.
Use the main menu to turn the vacuum
pump on.
Use the button on the control
panel:
6.
Re-set the machine with the button on the
touch screen.
Status line indicates ‘single
stroke’.
7.
Put the machine in manual mode
Use the button on the control
panel
8.
Now start up the process using the film in
feed button and/or button on the control
panel.
Use the button on the control
panel or machines in feed side
9.
The film infeed process starts up.
Main switch
Heating elements
