3.14 Drive gear
The drive chains are powered by an electric motor (see Figure 3.32).
The chain wheels are mounted on a shaft. This causes the chains always to run at the same
speed. There are two chain tensors in the drive gear. If the chain tension is too high or too low,
it can be easily adjusted with the adjusters. This procedure can be found in Part 2 of the
Manual.
Figure 3.32 Drive gear
Main shaft
Chain wheel
Chain adjusters
Electric motor
