4.4.18 Complete cutting
This menu is accessed by pressing the ‘SERVO CROSS CUTTING’ button in the main menu
(see Figure 4.39)
This screen shows you all settings needed for the complete cutting device.
Discharge time conveyor : The running time for the integrated conveyor after film advance.
Can be set here for what is optimal during process This ensures
that all products are out of the complete cutting device.
Discharge conveyor speed : The speed for the integrated conveyor after film advance.
Contour conveyor height : The height of the integrated conveyor can be changed to be
level with the discharge conveyor.
Lane conveyor speed : Speed for the discharge conveyor.
Test : Complete cutter makes a complete cycle to control its functions.
All red LEDs indicate their corresponding position of the cylinder movements.
The green LED indicates if the discharge conveyor is in place. When the discharge conveyor is
not in place the machine is not able to start.
The working of this complete cutter is described in paragraph 3.10.1
Press
Save
to store the settings in the current program.
Press
return
and the screen goes back to the previous menu.
Figure 4.39 Complete Cutting
