Getting to Know the Monitor
17
Side Panel Features
!
Self-Test Connector
You use the self-test connector when performing a Functional Self-Test to make sure the lead wires,
patient cable, and SmartMonitor 2 are working properly. See the section, Performing a Functional Self-
Test for more information.
Memory Card (Optional)
The Memory Card transfers monitor data out of the monitor to give to the physician. See the section on
Transferring Monitor Memory for more information.
M
e
m
o
r
y
C
a
r
d
Push button
to remove
Memory Card
Memory Card
LA
Connection
RA
Connection
