Setting Alarm and Recording Limits
20
Recording Menu
System Menu
The SmartMonitor 2 parameters for these menus are in the chart located in Appendix A.
Once the changes are completed turn the SmartMonitor 2 off by pressing the following buttons:
Press and hold the blue RESET button.
Press and release the gray POWER button.
Wait two seconds, and then release the RESET button.
When you power the SmartMonitor 2 off and then back on, the new values will be implemented.
The SmartMonitor 2 Parameters
The following menu flow is for All Menus. That encompasses menus for Alarms, Recording, and
Systems. To quickly access, for instance, an alarm setting, select the Alarm Menu.
Menu Option LCD Display Description of Option or Instructions Menu Path
PATIENT
NAME
PATIENT NAME
To enter the Patient Name:
Press Enter to begin entering patient name.
Press t or u to browse through the
alphabet and select the letter you need.
When the letter you want appears, press
Enter. Press Enter twice to place a space in
between the first and last name.
When you have finished the name, press t
or u until the ^ appears. Then press Enter.
The ^ is just before the letter “a”.
Press t to proceed to the next menu or u
to move to the previous menu.
All Menus
Alarm Menu
Record Menu
System Menu
PATIENT ID PATIENT ID
NUMBER
To enter the Patient ID:
Press t or u until Patient ID is displayed.
Press Enter to activate
Press t or u to browse through the
numbers and select the digit you need.
When the digit you want displays, press
Enter.
When you have finished the ID, press t or
u until the ^ appears. Then press Enter.
^ is just before “0”.
Press t to proceed to the next menu or u
to move to the previous menu.
All Menus
Alarm Menu
Record Menu
System Menu
