8
GA--A 202
1.7.1 Combination with POWER STICK M4 and, alternatively, POWER STICK M3
1.0
3.0
2.0
4.0
4.0
4.1
4.1
5.0
6.0
5.1
6.1
1.7.2 Legend
1.0 POWER CONTROL 2303 5.0 POWER STICK M3 with irrigation connector
(8563.311)
2.0 POWER STICK M4 5.1 Adapter for M3
3.0 Footswitch 6.0 Irrigation fluid container (only for 8563.311)
4.0 Suction pump 6.1 Irrigation tube kit (only for 8563.311)
4.1 Suction tube
.
NOTE!
Instead of POWER STICK M4, POWER STICK M3 with irrigation connector (8563.311) can be
connected to POWER CONTROL 2303 using adapter 2303.911.
