8.3 Technical data of POWER STICK
Model/type Designation
Length
mm
Cross section
mm
Weight
g
Speed
rpm
8564.021 POWER STICK M4 175 25 x 28 295 100 -- 6000
8564.851 Connection cable 3000 -- 275 --
8563.111 /.311 POWER STICK M3 175 27 x 31 240 100 -- 3000
8563.851 Connection cable 3000 -- 200 --
Protection against electric shock Type BF applied part
Degree of protection against the ingression of liquid IP X7
Degree of protection when used in the presence of flam-
mable mixtures
Device is not explosion--protected
(Do not use this device in flammable atmospheres)
Mode M3 (8563.111/.311)
Continuous operation duty type* with load interval
INT. 5min./5min.
Mode M4 (8564.021)
Continuous operation duty type* with load interval
INT. 3min./3min.
8.4 Techn ical data of footswitch
Degree of protection against the ingression of liquids IP X8
Degree of protection when used in the presence of flam-
mable mixtures
Device is not explosion--protected
(Do not use this device in flammable atmospheres)
Weight 4.0 kg (8.8 lbs)
Dimensions WxHxD 235 mm x 55 mm x 150 mm
8.5 Operating, storage, transport and shipping conditions
Operating conditions
+10Cto+40C , 30% to 75% rel. humidity,
atmospheric pressure 700 hPa to 1060 hPa
Storage, transport and shipping conditions
-- 2 0 Cto+60C , 10% to 90% rel. humidity,
atmospheric pressure 700 hPa to 1060 hPa
.
NOTE!
To prevent damage during the transport or shipment of the products we recommend using the original
packaging material.
