6.4 Connection to the RIWO NET SYSTEM
Touch-Screen
Monitor
CAN--BUS
Control computer
RS--232
RS--232
CAN--BUS termination
e.g.
POWER
CONTROL
e.g.
Light projector
e.g.
Camera
z.B.
Video printer
z.B.
Video recorder
RIWO CONTROL
Connection of headset microphone
CAN--BUS
CAN--BUS
.
IMPORTANT!
The device system must be operated via a “Separating transformer with DC coup-
ling”.
.
IMPORTANT!
The last device in the CAN--BUS chain requires a termination using the supplied
terminating resistor.
