7. Connecting Devices
This chapter explains how to display an image from an image output device, and write on the displayed
screen.
Connecting an External Device
You can connect an external device to this machine, display the device's image on the machine's screen,
and write on the displayed image.
In addition, you can control the computer screen with this machine by connecting the USB cable
between the computer and a port on the machine that supports the touch module.
• For details about the location and type of input/output terminals of this machine, see "Component
Names and Functions", Read This First.
• For details about connecting the touch module, see "Connecting the Touch Module", Read This
First.
Connecting Audio/Video Signals
Pay attention to the following notes when you connect cables:
• Please turn off all devices.
• Familiarize yourself with the audio/video ports on the machine and the devices you want to use.
Be aware that incorrect connections may adversely affect picture quality or result in the picture not
being displayed.
• Do not remove cables from the ports by pulling the cable itself. Always grasp and pull the
connectors at the end of the cable.
• Ensure that all cables are fully inserted and firmly seated.
Connecting the VGA Input
1. Connect the VGA jack on the display to the VGA output jack on a computer using a D-Sub
(15-pin) cable.
