About VESA Bracket
A mini PC (ultra-compact PC) can be mounted on the back of the machine using a VESA Bracket that
supports the VESA standard.
1. VESA Bracket
Item Specifications
Supported sizes
75 75 mm (2.95 inches)
100 100 mm (3.93 inches)
Load Capacity 5 kg (11.0 lb.)
• The above illustration is based on RICOH Interactive Whiteboard A6500 as an example.
Depending on the model used, the position and shape of the VESA Bracket may vary slightly.
11. Appendix
146
