Ricoh Aficio GX7000 User Manual

ZKKX030J
-14
-6
-2
0
+2
+6
0
+2
+6
+14
When horizontal lines beside the lightest gray square are broken, select the optimal adjustment value
by referring to the lines broken in the opposite direction. When the “+2” square is the lightest gray
square and the “+6” horizontal lines are broken in the opposite direction, the optimal adjustment
value is between “+3” and “+5”. After adjustment, check the adjustment result.
-14
-6
-2
0
+2
+6
0
+2
+6
+14
ZKKX040J
7. Press the [ ] or [ ]key to display [Adjustment], and then press the [#Enter] key.
Adj.Paper Feed:
Adjustment
8. Press the [ ] or [ ] key to enter the adjustment value (-14 to +14) from step 5, and then
press the [#Enter] key.
A:
(-14, +14) 0
9. Press the [Online] key.
The initial screen appears.
Registration
Follow the procedure below to adjust where to start printing on paper loaded in each paper tray after
checking the test pattern printed.
5. Maintaining
142
5

Ricoh Aficio GX7000 Specifications

Power

power source	100 – 120V, 50/60Hz
power consumption	35W or less
energy saver mode	5W or less

Printing Specifications

resolution	True 1200 x 1200 dpi, 600 x 600 dpi, 600 x 300 dpi (Maximum 3600 x 1200 dpi equivalent)
printing speed	29 pages-per-minute in B&W and full-color
first print speed	B&W: 6.5 seconds or less, Color: 9 seconds or less

Paper Handling

paper capacity	250-Sheet Standard Paper Tray, 100-Sheet Multi-Bypass Tray, 250-Sheet Paper Feed Unit
maximum paper capacity	600 sheets
output capacity	100 sheets (face up)

Weight and Dimensions

dimensions	21.4" x 21.9" x 10.4" / 545 x 558 x 269 mm
weight	42.1 lbs. / 19.1 kg
