Guide to Components
The names and functions of parts of the printer body, control panel, and options are explained.
Machine Body
This is a front view of the printer.
BAJ008S
1
2
3
5
4
11
6
7
8
9
10
BAJ034S
12
13
1. Top cover
Normally,
keep this cover closed. If you cannot locate paper jams, or jammed paper cannot be removed easily,
you can check the condition of paper from the top of the printer.
2. Tray 1 output ramp
Prints are delivered on top of the Tray 1 cover.
3. Tray 1 output ramp extension
Pull out when using large paper to keep the printed paper from falling.
4. Tray 1 cover
This is attached to Tray 1.
To load paper, lift off the Tray 1 cover.
If you want to print on paper larger than A4 or letter size, pull the Tray 1 cover extension.
Guide to Components
17
1

Table of Contents

Other manuals for Ricoh Aficio GX7000

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ricoh Aficio GX7000 and is the answer not in the manual?

Ricoh Aficio GX7000 Specifications

Power IconPower
power source100 – 120V, 50/60Hz
power consumption35W or less
energy saver mode5W or less
Printing Specifications IconPrinting Specifications
resolutionTrue 1200 x 1200 dpi, 600 x 600 dpi, 600 x 300 dpi (Maximum 3600 x 1200 dpi equivalent)
printing speed29 pages-per-minute in B&W and full-color
first print speedB&W: 6.5 seconds or less, Color: 9 seconds or less
Paper Handling IconPaper Handling
paper capacity250-Sheet Standard Paper Tray, 100-Sheet Multi-Bypass Tray, 250-Sheet Paper Feed Unit
maximum paper capacity600 sheets
output capacity100 sheets (face up)
Weight and Dimensions IconWeight and Dimensions
dimensions21.4" x 21.9" x 10.4" / 545 x 558 x 269 mm
weight42.1 lbs. / 19.1 kg
