Ricoh Aficio GX7000 User Manual

When using a non-recommended browser
When using Internet Explorer 3.02 or Netscape Navigator 4.05 or later versions, a simplified User
Guide is displayed.
• If the simplified User Guide does not automatically appear, in the CD-ROM's [unv] folder, open
index.htm.
Opening from the Icon
This section explains how to open User Guide from the desktop icon.
1. Double-click the [User Guide] icon on your desktop.
The browser opens, and then User Guide appears.
Opening from the [Start] Menu
This section explains how to open User Guide from the Windows Start menu.
1. On the [Start] menu, point to [All Programs], point to [Product Name], and then click
[Product Name User Guide].
The browser opens, and then User Guide appears.
• Depending on the settings made during installation, menu folder names may differ.
Opening from the Printer Driver
This section explains how to open User Guide from the printer driver.
1. In the printer properties dialog box, click [User Guide] on the [Setup] tab.
The browser opens, and then User Guide appears.
Opening from the CD-ROM
This section explains how to open User Guide from the supplied CD-ROM.
How to Read This Manual
15
1

Ricoh Aficio GX7000 Specifications

Power

power source	100 – 120V, 50/60Hz
power consumption	35W or less
energy saver mode	5W or less

Printing Specifications

resolution	True 1200 x 1200 dpi, 600 x 600 dpi, 600 x 300 dpi (Maximum 3600 x 1200 dpi equivalent)
printing speed	29 pages-per-minute in B&W and full-color
first print speed	B&W: 6.5 seconds or less, Color: 9 seconds or less

Paper Handling

paper capacity	250-Sheet Standard Paper Tray, 100-Sheet Multi-Bypass Tray, 250-Sheet Paper Feed Unit
maximum paper capacity	600 sheets
output capacity	100 sheets (face up)

Weight and Dimensions

dimensions	21.4" x 21.9" x 10.4" / 545 x 558 x 269 mm
weight	42.1 lbs. / 19.1 kg
