Ricoh Aficio GX7000 User Manual

BAJ027S
5
6
1. USB slot
Connect the USB cable from the computer here.
2.
Rear Cover
Remove this when attaching the duplex unit.
Remove this to open guide board, and then remove paper jammed inside the printer.
3. Vent
Air is vented here to prevent the inside of the printer from getting too warm. Do not lean anything against the vent
or block it in any way. If the inside of the printer gets too warm, a breakdown could occur.
4. Power inlet
Plug the power cord.
Plug one end of the power cord into the printer's power inlet and the other end into a wall outlet.
Connect the grounding wire attached to the power plug directly to a grounding terminal.
5. Guide board
To remove paper that has jammed inside the printer, open the guide board by removing the rear cover.
6. Ink collector unit cover
The ink collector unit for storing ink is installed in the printer.
Be careful not to spill the ink.
Remove the ink collector unit only when necessary.
Control Panel
The illustrations in this manual show the model. The model may differ slightly from
the illustrated model.
Guide to Components
19
1

Ricoh Aficio GX7000 Specifications

Power

power source	100 – 120V, 50/60Hz
power consumption	35W or less
energy saver mode	5W or less

Printing Specifications

resolution	True 1200 x 1200 dpi, 600 x 600 dpi, 600 x 300 dpi (Maximum 3600 x 1200 dpi equivalent)
printing speed	29 pages-per-minute in B&W and full-color
first print speed	B&W: 6.5 seconds or less, Color: 9 seconds or less

Paper Handling

paper capacity	250-Sheet Standard Paper Tray, 100-Sheet Multi-Bypass Tray, 250-Sheet Paper Feed Unit
maximum paper capacity	600 sheets
output capacity	100 sheets (face up)

Weight and Dimensions

dimensions	21.4" x 21.9" x 10.4" / 545 x 558 x 269 mm
weight	42.1 lbs. / 19.1 kg
