Ricoh Aficio GX7000 User Manual

• For details about what conditions the printer can be used under (ambient temperature and humidity
range), see p.31 "Checking the Computer and Installation Area".
•
See p.161 "Moving".
Printer Error
An error has occurred in the printer. Turn the power off once, and then turn it back on.
• If the printer is relocated from a cold area to a warm area or the printer is placed in a room where
the temperature varies greatly, condensation may form inside the printer causing errors. If this
happens, perform the decondensation procedure.
• For details about de-condensation, see p.145 "De-condensation".
• If the error still does not clear after the printer acclimates to room temperature and the power is turned
back on, contact your sales or service representative.
Network Interface Board Error
An error in the network interface board network function has occurred. Do the following:
1. Turn the printer off.
BAG052S
2. Turn the printer on.
If the message reappears, do the following:
3. Turn the printer off, and then unplug the power cord.
Unplug the power plug only after making sure the [Power] key indicator is off.
4. Turn the network interface board's screw counterclockwise and remove the board.
6. Troubleshooting
238
6

Ricoh Aficio GX7000 Specifications

Power

power source	100 – 120V, 50/60Hz
power consumption	35W or less
energy saver mode	5W or less

Printing Specifications

resolution	True 1200 x 1200 dpi, 600 x 600 dpi, 600 x 300 dpi (Maximum 3600 x 1200 dpi equivalent)
printing speed	29 pages-per-minute in B&W and full-color
first print speed	B&W: 6.5 seconds or less, Color: 9 seconds or less

Paper Handling

paper capacity	250-Sheet Standard Paper Tray, 100-Sheet Multi-Bypass Tray, 250-Sheet Paper Feed Unit
maximum paper capacity	600 sheets
output capacity	100 sheets (face up)

Weight and Dimensions

dimensions	21.4" x 21.9" x 10.4" / 545 x 558 x 269 mm
weight	42.1 lbs. / 19.1 kg
