Ricoh Aficio MP 8001 Service Manual

Error Codes
SM 27 D418
Fax Option
Type 9001
D418
Code Meaning Suggested Cause/Action
confidential or transfer
mode
 Replace the NCU or FCU.
 Try adjusting the tx level and/or cable
equalizer settings.
 The other end may have disconnected, or it
may be defective; try calling another machine.
 If the rx signal level is too low, there may be a
line problem.
Cross reference
 See error code 0-08.
0-20
Facsimile data not
received within 6 s of
retraining
 Check the line connection.
 Check the FCU - NCU connectors.
 Replace the NCU or FCU.
 Check for line problems.
 Try calling another fax machine.
 Try adjusting the reconstruction time for the
first line and/or rx cable equalizer setting.
Cross reference
 Reconstruction time - G3 Switch 0A, bit 6
 Rx cable equalizer - G3 Switch 07 (PSTN)
0-21
EOL signal (end-of-line)
from the other end not
received within 5 s of the
previous EOL signal
 Check the connections between the FCU,
NCU, & line.
 Check for line noise or other line problems.
 Replace the NCU or FCU.
 The remote machine may be defective or may
have disconnected.
Cross reference
 Maximum interval between EOLs and
between ECM frames - G3 Bit Switch 0A, bit 4
0-22
The signal from the other
end was interrupted for
more than the acceptable
modem carrier drop time
 Check the line connection.
 Check the FCU - NCU connectors.
 Replace the NCU or FCU.
 Defective remote terminal.
