Ricoh Aficio MP C2550 Service Manual

Bit Switches
D432/D433 88 SM
6
G3 mode selection for direct
line
0: Off
1:On
1: G3 communication through the direct line is
enabled.
7
Not used
Do not change the settings.
G3 Switch 01 [SP No. 1-105-002]
No FUNCTION COMMENTS
0-1
Not used
Do not change the settings.
2-3
Not used
Do not change the settings.
4
DIS frame length
0: 10 bytes 1: 4 bytes
1: The bytes in the DIS frame after the 4th byte will
not be transmitted (set to 1 if there are
communication problems with PC-based faxes
which cannot receive the extended DIS frames).
5
Not used
Do not change the setting.
6
Forbid CED/AMsam output
0: Off
1: On (Forbid output)
Do not change this setting (Default: 0: Off), unless
communication problem is caused by a CED or
ANSam transmission.
7
Not used
Do not change the setting.
G3 Switch 02 [SP No. 1-105-003]
No FUNCTION COMMENTS
0
G3 protocol mode used
0: Standard and non-standard
1: Standard only
Change this bit to 1 only when the other end can
only communicate with machines that send
T.30-standard frames only.
1: Disables NSF/NSS signals (these are used in
non-standard mode communication)
1-6
Not used
Do not change the settings.

Ricoh Aficio MP C2550 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed (Color)	25 ppm
Print Speed (Monochrome)	25 ppm
Print Resolution	600 x 600 dpi
Maximum Print Resolution	2400 x 600 dpi
Duplex Printing	Yes
Copy Speed (Color)	25 cpm
Copy Speed (Monochrome)	25 cpm
Copy Resolution	600 x 600 dpi
Memory (Maximum)	1 GB
Hard Disk Drive (Optional)	80 GB
Interface	USB 2.0, Ethernet 10/100Base-TX
Fax Transmission Speed	33.6 Kbps
Maximum Paper Size	A3
Scan Resolution	600 dpi
Zoom Range	25% - 400%
Paper Size	A4, A5, B5
Paper Weight	52 - 256 g/m²
PDL	PCL 6, PostScript 3
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac OS
