Ricoh Aficio MP C2550 Service Manual

Jam Detection
SM Appendix 7-5 D037/D038/D040/D041
Appendix:
Jam
Detection
Jam Code
SP
Display Description
LCD
Display
7504 248 Belt Lift Solenoid
The mainframe detects the belt lift
solenoid error from the internal finisher.
R1, R2
7504 249 Finisher Fan
The mainframe detects the finisher fan
error from the internal finisher.
R1, R2
7504 250 Punch Motor
The mainframe detects the lock signal
from the punch motor.
R1, R2
7504 251 Finisher Proof Exit
The mainframe detects the lock signal
from the registration motor of the punch
unit.
R1, R2
7504 252
FIN:Stapler Position
Error
The stapler unit stays on the jogger end
fence so that stapling is disabled.
R1, R2
7504 253 FIN:Job Data Error
Unexpected job data is sent to the
internal finisher from the mainframe.
R1, R2
 The jam location display depends on where a paper jam is detected at power-on.
ARDF (Original Jam)
Jam Code
SP
Display Description
LCD
Display
7505 1 At Power On Original is stack at power-on. P
7505 3 Skew Correction: ON
Skew correction sensor does not detect
paper.
P
7505 4 Registration: ON
Registration sensor does not detect
paper.
P
7505 5 Paper Exit: ON Exit Sensor does not detect paper. P
7505 53 Skew Correction: OFF Skew correction sensor does not turn P

Ricoh Aficio MP C2550 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed (Color)	25 ppm
Print Speed (Monochrome)	25 ppm
Print Resolution	600 x 600 dpi
Maximum Print Resolution	2400 x 600 dpi
Duplex Printing	Yes
Copy Speed (Color)	25 cpm
Copy Speed (Monochrome)	25 cpm
Copy Resolution	600 x 600 dpi
Memory (Maximum)	1 GB
Hard Disk Drive (Optional)	80 GB
Interface	USB 2.0, Ethernet 10/100Base-TX
Fax Transmission Speed	33.6 Kbps
Maximum Paper Size	A3
Scan Resolution	600 dpi
Zoom Range	25% - 400%
Paper Size	A4, A5, B5
Paper Weight	52 - 256 g/m²
PDL	PCL 6, PostScript 3
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac OS
