Ricoh Aficio MP C2550 Service Manual

Copier Installation
SM 2-9 D037/D038/D040/D041
Installaion
No. Description Q’ty Destination
19. CD-ROM Instruction – Network & General Setting Guide 1
20. CD-ROM Instruction – Security Reference 1
21. PostScript 3 Supplement
-67, -29, -21,
-19, -28
22. Printer Driver CD-ROM 1 -29, 28
23. Scanner Driver & Utility CD-ROM 1
24. Clear Cover 1
-57, -67, -29
2.3.4 INSTALLATION PROCEDURE
 Remove the tapes from the development units before you turn the main switch on.
The development units can be severely damaged if you do not remove the tapes.
Put the machine on the paper tray unit first if you install an optional paper tray unit at the
same time. Then install the machine and other options.
 Keep the shipping retainers after you install the machine. You may need them in
the future if you transport the machine to another location.
Tapes and Retainers
1. Remove all the tapes and retainers on the machine.
2. Remove all the tapes and retainers in trays 1 and 2.

Ricoh Aficio MP C2550 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed (Color)	25 ppm
Print Speed (Monochrome)	25 ppm
Print Resolution	600 x 600 dpi
Maximum Print Resolution	2400 x 600 dpi
Duplex Printing	Yes
Copy Speed (Color)	25 cpm
Copy Speed (Monochrome)	25 cpm
Copy Resolution	600 x 600 dpi
Memory (Maximum)	1 GB
Hard Disk Drive (Optional)	80 GB
Interface	USB 2.0, Ethernet 10/100Base-TX
Fax Transmission Speed	33.6 Kbps
Maximum Paper Size	A3
Scan Resolution	600 dpi
Zoom Range	25% - 400%
Paper Size	A4, A5, B5
Paper Weight	52 - 256 g/m²
PDL	PCL 6, PostScript 3
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac OS
