Ricoh Aficio MP C2550 Service Manual

Controller Options
D037/D038/D040/D041 2-100 SM
1. Turn off the main power switch if the machine is turned on.
2. Disconnect the network cable if it is connected.
3. Remove the slot cover [A] of SD slots ( x 1).
4. Turn the SD-card label face [B] to the rear of the machine. Then push it slowly into slot
1 until you hear a click.
5. Connect the network cable if it needs to be connected.
6. Turn on the main power switch.
7. Go into the SP mode and push “EXECUTE” with SP5-878-001.
8. Exit the SP mode and turn off the operation switch. Then turn off the main power
switch.
9. Turn on the machine power.
10. Do SP5990-005 (SP print mode -> Diagnostic Report).
11. Make sure the ROM number and firmware version in area [a] of the diagnostic report
are the same as those in area [b].
• [a]: “ROM Number/Firmware Version” – “HDD Format Option”
• [b]: “Loading Program” - “GW5a_zoffym”
Diagnostic Report: “ROM No. / Firmware
Version” [a]
“Loading Program” [b]
DataOverwriteSecurity Unit HDD Format Option:
D3775912A / 1.01m
GW5a_zoffym:
D3775912A / 1.01m
NOTE: The ROM number and firmware version number change when the firmware is
upgraded.
Rev. 02/2009
⇒
⇒

Ricoh Aficio MP C2550 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed (Color)	25 ppm
Print Speed (Monochrome)	25 ppm
Print Resolution	600 x 600 dpi
Maximum Print Resolution	2400 x 600 dpi
Duplex Printing	Yes
Copy Speed (Color)	25 cpm
Copy Speed (Monochrome)	25 cpm
Copy Resolution	600 x 600 dpi
Memory (Maximum)	1 GB
Hard Disk Drive (Optional)	80 GB
Interface	USB 2.0, Ethernet 10/100Base-TX
Fax Transmission Speed	33.6 Kbps
Maximum Paper Size	A3
Scan Resolution	600 dpi
Zoom Range	25% - 400%
Paper Size	A4, A5, B5
Paper Weight	52 - 256 g/m²
PDL	PCL 6, PostScript 3
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac OS
