Ricoh Aficio MP C2550 Service Manual

SC Tables
SM Appendix 4-7 D037/D038/D040/D041
Appendix:
Service Call
Conditions
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
 Defective SBU
 Defective harness
 Defective detection port on the BCU
1. Replace the harness.
2. Replace the SBU.
3. Replace the BCU.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
161 D IPU error
The error result of self-diagnostic by the ASIC on the i-controller is
detected.
 Defective i-controller
 Defective connection between i-controller and SBU
001 D
1. Check the connection between i-controller and SBU.
2. Replace the i-controller.
Detected an error during an access to the i-controller.
 Defective i-controller board
002 D
Replace the i-controller board.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
Copy Data Security Unit error
 The copy data security board is not detected when the copy data
security function is set "ON" with the initial setting.
 A device check error occurs when the copy data security function is
set "ON" with the initial setting.
165 D
 Incorrect installation of the copy data security board
 Defective copy data security board

Ricoh Aficio MP C2550 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed (Color)	25 ppm
Print Speed (Monochrome)	25 ppm
Print Resolution	600 x 600 dpi
Maximum Print Resolution	2400 x 600 dpi
Duplex Printing	Yes
Copy Speed (Color)	25 cpm
Copy Speed (Monochrome)	25 cpm
Copy Resolution	600 x 600 dpi
Memory (Maximum)	1 GB
Hard Disk Drive (Optional)	80 GB
Interface	USB 2.0, Ethernet 10/100Base-TX
Fax Transmission Speed	33.6 Kbps
Maximum Paper Size	A3
Scan Resolution	600 dpi
Zoom Range	25% - 400%
Paper Size	A4, A5, B5
Paper Weight	52 - 256 g/m²
PDL	PCL 6, PostScript 3
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac OS
