Ricoh Aficio MP C2550 Service Manual

SC Tables
SM Appendix 4-9 D037/D038/D040/D041
Appendix:
Service Call
Conditions
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
Polygon motor error 2: OFF timeout
The polygon mirror motor does leave the READY status within 3
seconds after the polygon motor switches off.
 Disconnected or defective harness to polygon motor driver board
 Defective polygon motor driver board
 Defective polygon motor
203 D
1. Check or replace the harness.
2. Replace the polygon motor.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
Polygon motor error 3: XSCRDY signal error
The SCRDY_N signal goes HIGH (inactive) while the laser diode is
firing.
 Disconnected or defective harness to polygon motor driver board
 Defective polygon motor
 Defective polygon motor driver board
204 D
1. Check or replace the harness.
2. Replace the polygon motor.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
220 D Laser synchronizing detection error: start position [K]: LD0
222 D Laser synchronizing detection error: start position [Y]: LD0
The laser synchronizing detection signal for the start position of the
LDB [K], [Y], is not output for two seconds after LDB unit turns on while
the polygon motor is rotating normally.
- -

Ricoh Aficio MP C2550 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed (Color)	25 ppm
Print Speed (Monochrome)	25 ppm
Print Resolution	600 x 600 dpi
Maximum Print Resolution	2400 x 600 dpi
Duplex Printing	Yes
Copy Speed (Color)	25 cpm
Copy Speed (Monochrome)	25 cpm
Copy Resolution	600 x 600 dpi
Memory (Maximum)	1 GB
Hard Disk Drive (Optional)	80 GB
Interface	USB 2.0, Ethernet 10/100Base-TX
Fax Transmission Speed	33.6 Kbps
Maximum Paper Size	A3
Scan Resolution	600 dpi
Zoom Range	25% - 400%
Paper Size	A4, A5, B5
Paper Weight	52 - 256 g/m²
PDL	PCL 6, PostScript 3
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac OS
