SC Tables
SM Appendix 4-19 D037/D038/D040/D041
Appendix:
Service Call
Conditions
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
the sensor while the polygon motor rotates.
Dirty ITB contact sensor
Defective ITB contact motor
Disconnected connector of ITB contact sensor or motor
Disconnected cable
1. Replace the ITB contact sensor.
2. Replace the ITB contact motor.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
ITB unit error
The machine detects the encoder sensor error.
Disconnect or defective harness
Defective encoder sensor
ITB unit installation error
Defective ITB unit motor
443 C
1. Connect or replace the harness.
2. Replace the encoder sensor.
3. Check if the ITB unit is correctly set.
4. Replace the ITB unit motor.
5. Replace the ITB unit.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
Paper transfer unit contact error
The paper transfer unit contact sensor does not detect the movement of
actuator at the sensor while the polygon motor rotates.
452 D
Defective paper transfer unit contact sensor
Defective paper transfer unit contact motor
