Ricoh Aficio MP C2550 Service Manual

SC Tables
SM Appendix 4-25 D037/D038/D040/D041
Appendix:
Service Call
Conditions
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
The motor lock signal error is detected for 10 seconds after the motor
lock signal was first detected.
 Defective controller box fan
 Disconnected or defective harness
 Defective DRB
 Defective BCU
1. Check or replace the harness.
2. Replace the controller box fan.
3. Replace the DRB.
4. Replace the BCU.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
Junction gate solenoid fan error
The motor lock signal error is detected for 10 seconds after the motor
lock signal was first detected.
 Defective junction gate solenoid fan
 Disconnected or defective harness
 Defective DRB
 Defective BCU
536 D
1. Check or replace the harness.
2. Replace the Junction gate solenoid fan.
3. Replace the DRB.
4. Replace the BCU.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
Fusing/Paper exit motor error 540 D
The BCU receives the lock signal 2.0 seconds after turning on the
fusing/paper exit motor.

Ricoh Aficio MP C2550 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed (Color)	25 ppm
Print Speed (Monochrome)	25 ppm
Print Resolution	600 x 600 dpi
Maximum Print Resolution	2400 x 600 dpi
Duplex Printing	Yes
Copy Speed (Color)	25 cpm
Copy Speed (Monochrome)	25 cpm
Copy Resolution	600 x 600 dpi
Memory (Maximum)	1 GB
Hard Disk Drive (Optional)	80 GB
Interface	USB 2.0, Ethernet 10/100Base-TX
Fax Transmission Speed	33.6 Kbps
Maximum Paper Size	A3
Scan Resolution	600 dpi
Zoom Range	25% - 400%
Paper Size	A4, A5, B5
Paper Weight	52 - 256 g/m²
PDL	PCL 6, PostScript 3
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac OS
