Ricoh Aficio MP C2550 Service Manual

System Service Mode
SM Appendix 9-13 D037/D038/D040/D041
Appendix:
SP Mode
Tables
The pressure roller has one lamp.
[Ready Temp Setting]
1108
Japan use only
007 Ready Temp Time *ENG
[22 to 60 / 22 / 0.1 sec/step]
1109 [Fusing Nip Band Check]
001 Execute -
[0 or 1 / 0 / 1]
Executes the nip band measurement
between fusing belt and pressure roller.
If the nip band width is not 8 mm, and
fusing is not good, replace the pressure
roller or install a new fusing unit.
Pre-Idling Time *ENG
[0 to 120 / 0 / 1 sec/step]
002
Specifies the fusing rotation time before executing SP1109-001.
Stop Time * ENG
[5 to 30 / 20 / 1 sec/step]
003
Specifies the time for measuring the nip.
1112 [Environmental Correct: Fusing]
Temp.: Threshold: Low *ENG
[10 to 23 / 17 / 1 deg/step]
001
Specifies the threshold temperature for low temperature condition.
Temp.: Threshold: High *ENG
[24 to 40 / 30 / 1 deg/step]
002
Specifies the threshold temperature for high temperature condition.
Low Temp. Correction *ENG
[0 to 15 / 5 / 1 deg/step]
003
Specifies the temperature correction for the heating roller. When the low
temperature condition (specified with SP1112-001) is detected, the value of this
SP is added to the heating roller temperature.

Ricoh Aficio MP C2550 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed (Color)	25 ppm
Print Speed (Monochrome)	25 ppm
Print Resolution	600 x 600 dpi
Maximum Print Resolution	2400 x 600 dpi
Duplex Printing	Yes
Copy Speed (Color)	25 cpm
Copy Speed (Monochrome)	25 cpm
Copy Resolution	600 x 600 dpi
Memory (Maximum)	1 GB
Hard Disk Drive (Optional)	80 GB
Interface	USB 2.0, Ethernet 10/100Base-TX
Fax Transmission Speed	33.6 Kbps
Maximum Paper Size	A3
Scan Resolution	600 dpi
Zoom Range	25% - 400%
Paper Size	A4, A5, B5
Paper Weight	52 - 256 g/m²
PDL	PCL 6, PostScript 3
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac OS
