Ricoh Aficio MP C2550 Service Manual

Caster Table (D488)
D037/D038/D040/D041 2-28 SM
table.
 Use the screw holes [B] and [C] if the one-tray paper feed unit (D425) is installed
on the caster table.
3. Grasp the handle [A] and grips [B] of the machine, if the copier is to be installed on the
caster table.
 Hold the handle and grips of the machine when you lift and move the machine.
4. Lift the copier or one-tray paper feed unit [C], and then install it on the caster table [D].
5. Pull out tray 2 of the mainframe or the tray of the one-tray paper feed unit.
6. Secure the machine or one-tray paper feed unit to the caster table (step screw x 2)
7. Reinstall the tray in the mainframe or one-tray paper feed unit.
8. Adjust the five leveling adjustors of the caster table.

Ricoh Aficio MP C2550 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed (Color)	25 ppm
Print Speed (Monochrome)	25 ppm
Print Resolution	600 x 600 dpi
Maximum Print Resolution	2400 x 600 dpi
Duplex Printing	Yes
Copy Speed (Color)	25 cpm
Copy Speed (Monochrome)	25 cpm
Copy Resolution	600 x 600 dpi
Memory (Maximum)	1 GB
Hard Disk Drive (Optional)	80 GB
Interface	USB 2.0, Ethernet 10/100Base-TX
Fax Transmission Speed	33.6 Kbps
Maximum Paper Size	A3
Scan Resolution	600 dpi
Zoom Range	25% - 400%
Paper Size	A4, A5, B5
Paper Weight	52 - 256 g/m²
PDL	PCL 6, PostScript 3
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac OS
