Ricoh Aficio MP C2550 Service Manual

System Service Mode
D037/D038/D040/D041 9-338 SM Appendix
5803 19 Inverter Sensor Inverter gate open Inverter gate close
5803 20 Duplex Exit Sensor Paper detected No paper detected
5803 21 Duplex Entrance Sensor Paper detected No paper detected
5803 22 ID/MUSIC Sn Shutter HP Sn Shutter open Shutter close
5803 23 HVPS:CB - -
5803 24 HVPS:T - -
5803 25 Right Door Open SW Door close Door open
5803 26 Right Lower Cover OP SW Cover close Cover open
5803 27 Mechanical Counter:Bk Not set Set
5803 28 Mechanical Counter:FC Not set Set
5803 29 Key Counter Set Sensor Set Not set
5803 30 Key Card Set Sensor Set Not set
5803 31 Toner End Sensor: K End Not end
5803 32 Toner End Sensor: C End Not end
5803 33 Toner End Sensor: M End Not end
5803 34 Toner End Sensor: Y End Not end
5803 35 Fusing Entrance Sensor Paper detected No paper detected
5803 36 Fusing Exit Sensor Paper detected No paper detected
5803 37 Paper Exit Sensor Paper detected No paper detected
5803 38 ITB Contact HP Sensor HP (Contact)
Not HP
(not contact)
5803 39 ITB T-Collect Bttl:Set SW Set Not set
5803 40 PCU T-Collect Bttl:Set SW Set Not set
5803 41 PCU T-Collect Bttl Full Sn Full Not full

Ricoh Aficio MP C2550 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed (Color)	25 ppm
Print Speed (Monochrome)	25 ppm
Print Resolution	600 x 600 dpi
Maximum Print Resolution	2400 x 600 dpi
Duplex Printing	Yes
Copy Speed (Color)	25 cpm
Copy Speed (Monochrome)	25 cpm
Copy Resolution	600 x 600 dpi
Memory (Maximum)	1 GB
Hard Disk Drive (Optional)	80 GB
Interface	USB 2.0, Ethernet 10/100Base-TX
Fax Transmission Speed	33.6 Kbps
Maximum Paper Size	A3
Scan Resolution	600 dpi
Zoom Range	25% - 400%
Paper Size	A4, A5, B5
Paper Weight	52 - 256 g/m²
PDL	PCL 6, PostScript 3
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac OS
