Ricoh Aficio MP C2550 Service Manual

System Service Mode
SM Appendix 9-343 D037/D038/D040/D041
Appendix:
SP Mode
Tables
6120 26 Relay Sensor Paper not detected Paper detected
6120 27 Tray Lower Sensor Lower Not lower
6120 28 Jogger HP Sensor Not HP HP
6120 29 Punch HP Sensor Not rear Rear Position
6120 30 Stapler Safety Sensor No staple Staple detected
6120 31 Staple Empty Sensor No staple Staple detected
6120 32 Punch Unit Sensor Not set Set
Table 1: Paper Size Switch (Tray 1/ 2)
Switch 1 is used for tray set detection.
0: Pushed, 1: Not pushed
Models Bit
North America Europe/Asia 2 1 0
11" x 17" SEF*
1
(A3 SEF)
A3 SEF*
1
(11" x 17" SEF)
1 0 0
8.5" x 14" SEF
*2
(B4 SEF)
B4 SEF
*2
(8.5" x 14" SEF)
0 0 0
A4 SEF A4 SEF 0 1 1
8.5" x 11" SEF 8.5" x 11" SEF 1 1 1
B5 SEF B5 SEF 1 1 0
11" x 81/2" LEF*
3
(A4 LEF)
A4 LEF*
3
(11" x 81/2" LEF)
0 0 1
10.5" x 7.25" LEF*
4
(B5 LEF)
B5 LEF*
4
(10.5" x 7.25" LEF)
0 1 0
A5 LEF A5 LEF 1 0 1

Ricoh Aficio MP C2550 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed (Color)	25 ppm
Print Speed (Monochrome)	25 ppm
Print Resolution	600 x 600 dpi
Maximum Print Resolution	2400 x 600 dpi
Duplex Printing	Yes
Copy Speed (Color)	25 cpm
Copy Speed (Monochrome)	25 cpm
Copy Resolution	600 x 600 dpi
Memory (Maximum)	1 GB
Hard Disk Drive (Optional)	80 GB
Interface	USB 2.0, Ethernet 10/100Base-TX
Fax Transmission Speed	33.6 Kbps
Maximum Paper Size	A3
Scan Resolution	600 dpi
Zoom Range	25% - 400%
Paper Size	A4, A5, B5
Paper Weight	52 - 256 g/m²
PDL	PCL 6, PostScript 3
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac OS
