Ricoh Aficio MP C2550 Service Manual

Component Layout
D331 12 SM
Size
Switches
SW1 Tray Cover Detects whether the tray cover is opened or not. 9
SW2 Upper Tray Set
Detects whether the upper tray is opened or
not.
4
SW3 Lower Tray Set Detects whether the lower tray is opened or not. 14
Magnetic Clutches
MC1
Upper Paper
Feed
Starts paper feed from the upper tray. 7
MC2
Lower Paper
Feed
Starts paper feed from the lower tray. 10
MC3 Relay Drives the relay rollers. 8
PCBs
PCB1 Tray Main
Controls the paper tray unit and communicates
with the copier/printer.
22
Others
H1
Optional Tray
Heater
Removes humidity from the paper in the trays. 17

Ricoh Aficio MP C2550 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed (Color)	25 ppm
Print Speed (Monochrome)	25 ppm
Print Resolution	600 x 600 dpi
Maximum Print Resolution	2400 x 600 dpi
Duplex Printing	Yes
Copy Speed (Color)	25 cpm
Copy Speed (Monochrome)	25 cpm
Copy Resolution	600 x 600 dpi
Memory (Maximum)	1 GB
Hard Disk Drive (Optional)	80 GB
Interface	USB 2.0, Ethernet 10/100Base-TX
Fax Transmission Speed	33.6 Kbps
Maximum Paper Size	A3
Scan Resolution	600 dpi
Zoom Range	25% - 400%
Paper Size	A4, A5, B5
Paper Weight	52 - 256 g/m²
PDL	PCL 6, PostScript 3
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac OS
