Replacing the Maintenance Kit
129
6
D Insert the new transfer roller by placing its underside edge into the grooves
shown in the illustration.
E Secure the transfer roller using the green fastening clips mentioned in step
B
.
The transfer roller appears insecurely set, but this is intentional.
F Close the front cover (A).
AET165S
AET166S
