Attaching IEEE 1284 Interface Board Type A
39
2
Attaching IEEE 1284 Interface Board Type A
R
CAUTION:
Important
❒ Before handling the 1284 interface board, touch something metal to discharge
static electricity. Static electricity thing damage the 1284 interface board.
❒ Do not subject the 1284 interface board to physical shocks.
A Check the package contains the following:
❖ IEEE 1284 Interface Board Type A
B Turn off the power, and then unplug the power cable.
C Loosen the two screws and remove the cover of the 1284 interface board in-
stallation unit.
The removed cover is not used when installing the 1284 interface board.
• Do not touch inside the controller board compartment. Doing so may cause
a machine malfunction or a burn.
ABT041S1
AQC091S
