Ricoh AficioSP C410DN - Reading the LED Lamps

Network Connection
57
3
Reading the LED Lamps
❖ For standard ethernet port
1. Yellow: comes on when 100BASE-
TX is being used. It comes off when
10BASE-T is being used.
2. Green: comes on when the printer
is properly connected to the net-
work.
❖ For gigabit ethernet board
1. Green: comes on when 10BASE-T
is being used.
2. Yellow: comes on 100BASE-TX is
being used.
Green and yellow lamps are lit when
1000BASE-T is being used.
AQC070S
AQC070S
