Ricoh AficioSP C410DN - When the Paper Misfeed Message Appears (Cover A)

Removing Misfed Paper
172
10
When the Paper Misfeed Message Appears
(Cover A)
• If the “Press A to open cover and remove paper.” message appears:
A paper misfeed occurs in the paper feeding. Open the front cover (A) to re-
move the misfed paper.
R
CAUTION:
R
CAUTION:
Important
❒ Remove the paper from the bypass tray before opening the front cover.
❒ If a misfeed occurs when using the bypass tray, open the front cover, and then
remove the misfed paper.
A Carefully open the printer's front cover (A) of by pulling left and right side
levers.
• The inside of the machine becomes very hot. Do not touch the parts with a
“v” label (means hot surface). Touching a part with a “v” label (means hot
surface) could result in a burn.
• When pulling the paper tray out, be careful not to pull it strongly. If you do,
the tray might fall and cause an injury.
AQC018S
