Installing Options
50
2
Attaching VM Card Type D
Important
❒ Protect VM Card Type D from physical shocks.
❒ Use the right slot for the VM card.
A Check the package contains the following:
❖ VM Card Type D
B Turn off the power, and then unplug the power cable.
C Remove the cover of the controller board's center expansion card slot.
D Carefully insert the VM card, until the card clicks into place.
AET104S
AQC105S
AQC106S
To Next Page
