Replacing Consumables and Maintenance Kit
128
6
Replacing the Transfer Roller
A Carefully open the printer's front cover (A) of by pulling left and right side
levers.
B Pinch the green clips on both ends of the transfer roller.
Do not touch the roller area of the transfer roller. It may stain your hands or
clothes.
C Pull out the transfer roller.
AQC018S
AET163S
AET164S
To Next Page
