Available Options
13
2
Caution when re-installing the controller board
This section describes handling the controller board when installing options.
If you slide out the controller board to install the SDRAM module, the user ac-
count enhance unit, or the printer hard disk, carefully follow the instruction be-
low to re-install the controller board.
Re-install the controller board into the printer by pushing the bottom center
area of the board, as shown in the illustration.
Important
The following may occur if the controller board is not properly installed:
all control panel indicators are lit.
no control panel indicators is lit.
the “SC670” error message appears on the display.
AQC004S
