Ricoh AficioSP C410DN - 4 Configuration; Ethernet Configuration

63
4. Configuration
Ethernet Configuration
Make the following network settings according to the network interface you are
using.
You can use SmartDeviceMonitor for Admin or a Web browser to make IP ad-
dress-related settings in a TCP/IP-capable environment.
Important
❒ Configure the printer for the network using the control panel.
❒ The following table shows the control panel settings and their default values.
These items appear in the “Host Interface” menu.
Note
❒ If [Auto-Obtain (DHCP)] is in use, the IP address, subnet mask, and gateway ad-
dress are all set automatically.
❒ Make this setting only when it is necessary. See Software Guide.
Setting Name Value
Auto– Obtain (DHCP) On
IPv4 Address 011.022.033.044
Subnet Mask 000.000.000.000
Gateway Address 000.000.000.000
Frame Type (NW) Auto
Effective Protocol • IPv4:
Effective
•IPv6:
Effective
• NetWare:
Effective
•SMB:
Effective
• AppleTalk:
Effective
Ethernet Speed Auto
LAN Type Auto
