Replacing the Maintenance Kit
131
6
D
Prepare
a new fusi
ng uni
t.
E
Align the new
fusing unit with the left and righ
t rails.
F
Push the fusing unit carefully in, until it stops. Then, pull up the fixing lever.
G
Close the front cover (A
).
AET183S
AQC184S
AQC181S
142
