Specifications
187
11
IEEE 802.11b Interface Unit Type I
❖ Transmission Spec.:
Based on IEEE 802.11b (Wireless LAN)
❖ Protocol:
IPv4, IPv6, IPX/SPX, AppleTalk
Note
❒ SmartDeviceMonitor and Web Image Monitor are supported.
❖ Data Transfer Speed:
Auto select from below speed
1 Mbps, 2 Mbps, 5.5 Mbps, 11 Mbps
❖ Frequency Range:
• Inch version:
2412-2462 MHz (1-11 channels)
❖ Transmittable Distance:
1 Mbps 400 m
2 Mbps 270 m
5.5 Mbps 200 m
11 Mbps 140 m
*1
These figures are a guideline for outdoor use. In general, the transmittable dis-
tance indoors is 10-100 m, depending on the environment.
❖ Transmission Mode:
ad hoc mode and infrastructure mode
IEEE 1284 Interface Board Type A
❖ Transmission Spec.:
IEEE 1284
❖ Required cable:
Standard IEEE 1284 compliant Micro Centronics 36 pin cable
