Installing Options
18
2
C Grasp the handles and carefully pull out the controller board.
Using both hands, slide the controller board completely out.
D Place the controller board on a flat surface, and then loosen the four screws
to remove the cover.
The screws cannot be fully removed.
AQC640S
AQC650S
AQC660S
