IP-FAX Specifications
Network:
Local Area Network
Ethernet/10base-T, 100base-TX
IEEE1394 (IP over 1394)
IEEE802.11b (wireless LAN)
Scan line density:
8 x 3.85 lines/mm, 200 x 100dpi (standard characters)
8 x 7.7lines/mm, 200 x 200dpi (detailed characters)
Original size: Maximum A3 or 11"x 17" (DLT)
Maximum scanning size:
Standard: A3, 297mm x 432mm
Irregular: 297mm x 1200mm
Transmission protocol: Recommended: T.38 Annex protocol, TCP, UDP/IP communication
Compatible machines: IP-Fax compatible machines
IP-Fax transmission
function:
Specify IP address and send fax to an IP-Fax compatible fax through a
network.
Also capable of sending fax from a G3 fax connected to the public telephone
lines via a VoIP gateway.
IP-Fax reception function:
Receive a fax sent from an IP-Fax compatible fax through a network.
Also capable of receiving fax from a G3 fax connected the public telephone
lines via a VoIP gateway.
IP-FAX Specifications
143
