Bit Switches
• Do not adjust a bit switch or use a setting that is described as “Not used”, as this may cause the
machine to malfunction or to operate in a manner that is not accepted by local regulations. Such bits
are for use only in other areas, such as Japan.
• Default settings for bit switches are not listed in this manual. Refer to the System Parameter List printed
by the machine.
System Switches
System Switch 00 [SP No. 1-101-001]
No FUNCTION COMMENTS
0
Dedicated transmission parameter
programming
0: Disabled, 1: Enabled
Set this bit to 1 before changing any dedicated transmission
parameters.
Reset this bit to 0 after programming dedicated transmission
parameters.
1 Not used Do not change
2
Technical data printout on the
Journal
0: Disabled
1: Enabled
1: Instead of the personal name, the following data are
listed on the Journal for each G3 communication.
e.g. 0000 (1) // 32 (2) V34 (3) // 288 (4) // 264 (5) // L0100 (6) 03 (7) 04 (8)
(1): EQM value (Line quality data). A larger number means more errors.
(2): Symbol rate (V.34 only)
(3): Final modem type used
(4): Starting data rate (for example, 288 means 28.8 kbps)
(5): Final data rate
(6): Rx revel (refer to the note after this table for how to read the rx level)
(7): Total number of error lines that occurred during non-ECM reception.
(8): Total number of burst error lines that occurred during non-ECM reception.
4. Service Tables
50
To Next Page
