Ricoh C2000

Communication Switch 1F - Not used (do not change the settings)
G3-1 Switches
G3 Switch 00 [SP No. 1-105-001]
No FUNCTION COMMENTS
0-1
Monitor speaker during
communication (tx and rx)
Bit 1: 0, Bit 0: 0 = Disabled
Bit 1: 0, Bit 0: 1 = Up to Phase B
Bit 1: 1, Bit 0: 0 = All the time
Bit 1: 1, Bit 0: 1 = Reserved
(0, 0): The monitor speaker is disabled all through the
communication.
(0, 1): The monitor speaker is on up to phase B in the T.30
protocol.
(1, 0): Used for testing. The monitor speaker is on all through
the communication. Make sure that you reset these bits after
testing.
2
Monitor speaker during memory
transmission
0: Disabled 1: Enabled
1: The monitor speaker is enabled during memory
transmission.
3-7 Not used Do not change the settings.
G3 Switch 01 [SP No. 1-105-002]
No FUNCTION COMMENTS
0-1 Not used Do not change the settings.
2-3 Not used Do not change the settings.
4
DIS frame length
0: 10 bytes 1: 4 bytes
1: The bytes in the DIS frame after the 4th byte will not be
transmitted (set to 1 if there are communication problems
with PC-based faxes which cannot receive the extended
DIS frames).
5 Not used Do not change the setting.
6
Forbid CED/AMsam output
0: Off
1: On (Forbid output)
Do not change this setting (Default: 0: Off), unless
communication problem is caused by a CED or ANSam
transmission.
7 Not used Do not change the setting.
4. Service Tables
78
4
