NCU Parameters
The following tables give the RAM addresses and the parameter calculation units that the machine uses
for ringing signal detection and automatic dialing. The factory settings for each country are also given.
Most of these must be changed by RAM read/write (SP2-102), but some can be changed using NCU
Parameter programming (SP2-103); if SP2-103 can be used, this will be indicated in the Remarks column.
The RAM is programmed in hex code unless (BCD) is included in the Unit column.
Address Function
680500
Country/Area code for NCU parameters
Use the Hex value to program the country/area code directly into this address, or use
the decimal value to program it using SP2-103-001
Country
/Area
Decimal Hex
Country
/Area
Decimal Hex
France 00 00 USA 17 11
Germany 01 01 Asia 18 12
UK 02 02 Hong Kong 20 14
Italy 03 03 South Africa 21 15
Austria 04 04 Australia 22 16
Belgium 05 05 New Zealand 26 17
Denmark 06 06 Singapore 24 18
Finland 07 07 Malaysia 25 19
Ireland 08 08 China 26 1A
Norway 09 09 Taiwan 27 1B
Sweden 10 0A Korea 28 1C
Switzerland 11 0B Turkey 32 20
Portugal 12 0C Greece 33 21
Holland 13 0D Hungary 34 22
Spain 14 0E Czech 35 23
4. Service Tables
94
4
