IP Fax Switches
IP Fax Switch 00 [SP No. 1-111-001]
No. FUNCTION COMMENTS
0 Not used Do not change this setting.
1
IP Fax Transport
0: TCP, 1: UDP
Selects TCP or UDP protocol for IP-Fax
2
IP Fax single port selection
0: OFF, 1: ON (enable)
Selects single data port.
3
IP Fax double ports (single data port)
selection
0: OFF, 1: ON (enable)
Selects whether IP-Fax uses a double port.
4
IP Fax Gatekeeper
0: OFF, 1: ON (enable)
Enables/disables the communication via the
gatekeeper for IP-Fax.
5
IP Fax T30 bit signal reverse
0: LSB first, 1: MSB first
Reverses the T30 bit signal.
6
IP Fax max bit rate setting
0: Not affected, 1: Affected
When "0" is selected, the max bit rate does not affect
the value of the DIS/DCS.
When "1" is selected, the max bit rate affects the
value of the DIS/DCS.
7
IP Fax received telephone number
confirmation
0: No confirmation,
1: Confirmation
When "0" is selected, fax data is received without
checking the telephone number.
When "1" is selected, fax data is received only when
confirming that the telephone number from the
sender matches the registered telephone number in
this machine. If this confirmation fails, the line is
disconnected.
IP-Fax Switch 01 [SP No. 1-111-002]
No. FUNCTION COMMENTS
4. Service Tables
86
4
