0-3
Select IP FAX Delay Level Raise the level by selecting a higher setting if too
many transmission errors are occurring on the
network.
If TCP/UDP is enabled on the network, raise this
setting on the T.30 machine. Increasing the delay
time allows the recovery of more lost packets.
If only UDP is enabled, increase the number of
redundant packets.
Level 1 to 2: 3 Redundant packets
Level 3: 4 Redundant packets
Bit3 Bit2 Bit1 Bit0 Setting
0 0 0 0 Level 0
0 0 0 1 Level 1
0 0 1 0 Level 2
0 0 1 1 Level 3
4-7 IP Fax preamble wait time setting
Selects the preamble wait time.
[00 to 0f]
There are 16 values in this 4-bit binary switch
combination.
Waiting time: set value level x 100 ms
Max: 0f (1500 ms) Min: 00 (No wait time)
The default is "0000" (00H).
IP Fax Switch 02 [SP No. 1-111-003]
No. FUNCTION COMMENTS
0
IP Fax bit signal reverse setting
0: Maker code setting
1: Internal bit switch setting
When "0" is selected, the bit signal reverse method
is decided by the maker code.
When "1" is selected, the bit signal reverse method
is decided by the internal bit switch.
(When communicating between IP Fax devices, LSB
first is selected.)
1
IP Fax transmission speed setting
0: Modem speed
1: No limitation
Selects the transmit speed for IP Fax communication.
2
SIP transport setting
0: TCP
1: UDP
This bit switch sets the transport that has priority for
receiving IP Fax data.
This function is activated only when the sender has
both TCP and UDP.
Bit Switches
87
