1: On
3-5 Not used Do not change these settings.
6-7 Memory read/write by RDS
Bit 7: 0, Bit 6: 0
Always disabled
Bit 7: 0, Bit 6: 1
User selectable
Bit 7: 1, Bit 6: 0
User selectable
Bit 7: 1, Bit 6: 1
Always enabled
(0,0): All RDS systems are always locked out.
(0,1), (1,0): Normally, RDS systems are locked out, but the
user can temporarily switch RDS on to allow RDS
operations to take place. RDS will automatically be locked
out again after a certain time, which is stored in System
Switch 03. Note that if an RDS operation takes place, RDS
will not switch off until this time limit has expired.
(1,1): At any time, an RDS system can access the machine.
System Switch 03 [SP No. 1-101-004]
No FUNCTION COMMENTS
0-7
Length of time that RDS is
temporarily switched on when bits 6
and 7 of System Switch 02 are set
to “User selectable”
00 - 99 hours (BCD).
This setting is only valid if bits 6 and 7 of System Switch 02
are set to “User selectable”.
The default setting is 24 hours.
System Switch 04 [SP No. 1-101-005]
No FUNCTION COMMENTS
0-2 Not used Do not change these settings.
3
Printing dedicated tx parameters on
Quick/Speed Dial Lists
0: Disabled
1: Enabled
1: Each Quick/Speed dial number on the list is printed with
the dedicated tx parameters (10 bytes each).
The first 10 bytes of data are the programmed dedicated
tx parameters; 34 bytes of data are printed (the other 24
bytes have no use for service technicians).
4-7 Not used Do not change these settings.
System Switch 05 - Not used (Do not change the factory settings.)
System Switch 06 - Not used (Do not change the factory settings.)
4. Service Tables
52
